Product configurator Configurator handy-lift 100 khl05 Vertikal

Configuration

Double track crane rail lane 300 with transfer plate and energy guiding Position 1.0 ANr.: KHL098 Total weight 2.6 kg Kranbahn Zweispur_1080x1080px
Double track crane bridge with transfer plate and energy guiding for handy-lift 100 Position 2.0 ANr.: BHL004 96489_1080x1080px
Inductive position query trolley single track / double track handy-lift 100 - 500 Position 3.0 ANr.: BHL017 Total weight 0.42 kg BHL017_1080x1080px
Inductive Position Query Crane Bridge Single Track / Double Track Position 4.0 ANr.: BHL016 Total weight 0.6 kg 66013_3_1080x1080px
Position measuring system, horizontal axis on crane rail Position 5.0 ANr.: VHL016 134797_3_1080x1080px
Position measuring system horizontal axis on crane bridge Position 6.0 ANr.: VHL024 119655_3_1080x1080px
Detent roller with ramp for crane bridges, single track / double track Position 7.0 ANr.: BHL015 Total weight 1.11 kg 96471_2_1080x1080px
Detent roller with drive-on ramp trolley double track handy-lift 100–500 Position 8.0 ANr.: BHL014 Total weight 1.11 kg 96475_2_1080x1080px
Retraction Crane Bridge Single Track / Double Track Position 9.0 ANr.: BHL012 133943_3_1080x1080px
Retraction double lane trolley handy-lift 100 - 500 Position 10.0 ANr.: BHL011 128363_4_1080x1080px
Toolholder System BAS010 Position 11.0 ANr.: KHL019 Total weight 0.71 kg Total build-up dimension 65 mm BAS009_n_1080x1080px
handy-lift 100 double track with balancer Position 12.0 ANr.: KHL046 Total weight 10.52 kg BHL100_1080x1080px
Inductive home position query vertical axis handy-lift 100 Position 13.0 ANr.: KHL086 48072_1080x1080px
Spring balancer Position 16.0 ANr.: KHL038 Spring balancer series 9336-9340 1080x1080
Request without concern Every requested configuration is checked for plausibility by our sales team.
